Soft Tube Screen Printing, Varnishing And Hot Foil Stamping Machine
4 Colors Screen Printer
Catalog
04_compressed.pdf
Application:
SRS1669-RT104CH is a new product for soft tube, with varnishing and
four color screen printing and 1 color hot-stamping for cosmetic
soft tubes.
This equipment is designed with high precision ( tolerance control
is less than 0.2mm) !!
Automatic silk screen overprinting and hot stamping, it adope
independent servo variable frequency apeed regularting device. The
printing speed can reach up to 70pcs/min.
Servo gearless design, faster replacement of fixture, simpler, less
vulnerable parts.
Features:
1. This machine is equipped automatic loading and unloading
systems, mechanical devices combined with PLC control.
2. Adopted main components from Rexroth, Schneider, SMC, Mitsubishi
etc; Mechanical parts made by CNC dirtctly from CAD design.
3. Adopted touch screen interface. Quick setup & quick toolings
change.
4. Adopted with No-object No-printing system, auto counter, safety
guard, out of working alarm device and auto separating device for
faulty printing.
5. Auto optical registration system, pre-printing & after printing
coating systems. Can be equipped by order.
6. Automatic feeder can be designed for specific products to
increase efficiency.
Technical Specifications
| Model | SRS1669-RT104CH |
| Printing stations | 6 (4 screen printing colors, 1 col hot stamping and 1 vanishing) |
| Printing speed | Up to 70pcs/min |
| Max. printing area | L250mm X W160mm |
| Product diameter | 12 - 60mm |
| Product height | 220mm |
| Air presser | 6-7 bar |
| Power | 380V 50/60HZ |
Senny in exhibition:
We Senny Printing Equipment Co. Ltd also can design the machine
with screen printing, hot stamping, varnishing and labeling
functions all-in-one. Any questions regarding the innovative
printing way or container shapes, kindly contact below:
