Automatic Labeling Machine Circumferential Surfaces High Accuracy
And Efficiency
Applicable Labels:
Covers a wide range of label types, including self-adhesive labels,
self-adhesive films, electronic supervision codes, bar codes, and
more, meeting diverse labeling material requirements.
Applicable Products:
Suitable for labeling on products with various surface types, such
as side planes, side surfaces, large curved surfaces, and
circumferential surfaces, ensuring stable and accurate labeling for
different product structures.
Application Industries:
Widely applied in multiple industries, including printing,
cosmetics, food, toys, daily chemicals, electronics, plastics,
medicine, etc., adapting to the labeling needs of different
industrial sectors.
Application Examples:
Typical application scenarios include labeling on shampoo flat
bottles, lubricant flat bottles, mineral water square bottles, wine
bottles, and other similar products, demonstrating practical
adaptability in daily production.
Technical Specifications(The following are the technical parameters of the standard model.
Other special requirements and functions can be customized):
| Model | SY500 | Labeling accuracy | ±1mm |
| Sticker length | 20mm～220mm | Sticker turning out speed | 5～25m/min |
| Sticker width | 20mm～150mm | Labeling speed | 30～150pcs/min |
| Product length | 20mm～250mm | Conveying speed | 5～35m/min |
| Product width | 30mm～90mm | Weight | 370kg |
| Product height | 60mm～280mm | Power voltage | 220V 50HZ |
| Product diameter | 40mm～110 mm | Power | 2KW |
| Sticker roll's external diameter | Φ280mm | Conveying oriention | fm left to side |
| Sticker roll's inner diameter | Φ76mm | Machine dimensions | 3000*1400*1600mm |
SY500 Workflow:
Product feeding - Transportation - Guiding the product to the right
direction - Top pressure transportation - Inspection - Labeling -
Pressure labeling - Secondary pressure labeling (some products) -
Product output.
Sample
About us:
SENNY PRINTING EQUIPMENT CO.,LTD was established in the year 2004,
it is specialized in designing and manufacturing precise automatic
screen printing machines, stick labler machines, hot stamping
machines and auxiliary equipments. Meanwhile, they can design any
kinds of automatic printing machines according to customers'
requirements.
SENNY has very good designers. The founder of SENNY was engaged in
designing and developing screen printing machines early from the
year 1994, and he got many achievements: he designed the first
automatic screen printing machine; automatic screen printing
machine for big iron pails; four colors sereen printing machine for
big oil kettles; automatic screen printing machines controlled by
module independently for bottles; automatic screen printing machine
for pails from 10L 1o 20L(3colors and 7colors) and so on so forth.
In order to improve our products, SENNY adopts the advantages of
the similar products in or abroad, and we also take customers'
comments and suggestions into consideration. With the innovation
and improvement for many years, the products produced by SENNY now
are in a leading position in the domestic markets. And it also
sales well all around the world.
With the mission“Excellence,Creation,Sincerity,Quality!”,SENNY
insists on providing high--quality products and services,
dedicating to exploring the new markets and seeking for mutual
benefit and win-win state with our customers.
